| Function |
Integrated Type |
| Measuring Range |
5m, 10m, 15m, 20m, 30m |
| Measurement Accuracy |
0.5% - 1% |
| Resolution Ratio |
3mm or 0.1 % (Which ever is greater) |
| Display |
LCD |
| Analog output |
4-line system, 4-20 mA 510 Ω load |
| 2-line system, 4-20 mA 250 Ω load |
| Relay Output |
2 group (i.e. AC 250V/8A or DC 30V/5A) optional, |
| State Programmable |
| Power Supply |
Standard configuration: 24 VDC |
| Optional: 220V AC ± 15 % 50 Hz |
| Ambient Temperature |
Display Instrument: -20 ~+80 Deg C |
| Communication |
485, 232 Communication (optional) (Manufacture) (Agreement) |
| IP Grade |
Display Instrument: IP66 Probe: IP68 |
| Probe Cable |
Display Instrument:- IP66, Probe: IP68 |
| Probe Installation |
Select type based on measuring range and probe |
